Programmable Rheometer
Programmable Rheometer
BGD offers several rheometer models tailored to different material rheological properties. Test operators can customize testing programs (e.g., automatic shear rate adjustment) and leverage specialized software to comprehensively analyze material rheology, including simulations of real-world application scenarios.
Product Details
◆ Conforms ISO 1652，ISO 2555，ISO 3219，ASTM D2196，ASTM D2983 etc.
◆ 7-inch HD touchscreen：User-friendly interface with clear, detailed display.
◆ High-precision stepper motor drive：Stepless speed adjustment, accurate rotation, smooth operation, and noise-free performance. Unaffected by AC voltage fluctuations.
◆ Built-in electronic level：Real-time leveling status display for quick and easy adjustment.
◆ Magnetic spindle mounting：Reduces shaft wear during spindle changes, enhancing durability.
◆ Reinforced shaft design：Engineered for long-term reliability.
◆ Switching power adapter：Wide voltage input range with strong anti-interference capability.
◆ Real-time sampling technology allows for the observation of viscosity changes even at low speeds without the need for waiting.
◆ Programmable testing：Supports timed measurements, programmable speed/temperature ramping (requires optional temperature-controlled small-sample adapter).
◆ Real-time curve display ：Visualize viscosity vs. time, viscosity vs. speed, and viscosity vs. temperature (with optional adapter) trends during testing.
◆ Multi-unit conversion：Dynamic and kinematic viscosity units interchangeable; automatic calculations.
◆ Factory-calibrated & user-recalibratable：Full-range linear calibration via computer; user-adjustable.
◆ Optional rheology software：PC-controlled operation and advanced data analysis for comparative rheological studies.
Main Technical Parameters
| Ordering Information →
Parameters ↓ |
BGD 168/L | BGD 168/M | BGD 168/H |
| Measurement Range (mPa.s) | 1-6 M | 50-40M | 400-320M |
| R.P.M (per min) | 0.1-250 | ||
| Rotors | LV1、LV2、LV3、LV4 （LV0 for optional） |
RV2、RV3、RV4、RV5、RV6、RV7 （RV1 for optional） |
|
| Measurement
Accuracy |
±1.0% (of the full range) | ||
| Repeatability | ±0.5% (of the full range) | ||
| Power Supply | Power Adapter （Input：110/220 V；50 /60 Hz； Output：12V；2A) | ||
| Optional Accessories | BGD 162/Z-004—UL Adapter（LV0 rotor+Specified Container）
BGD 168/Z-003—Small Sample Adapter（SC21，SC27，SC28，SC29 four rotors，and the max. measuring range would be different） BGD 168/Z-004—Rheometer Control and Data Analysis Software BGD 845/846— Low-high Temperature Circulating Bath |
||
(M=1 million)
